Dot Trimless Series

Dot Trimless 48V Magnetic Recessed Round Flood Light, 10W Embedded Led Ceiling Light

SKU D2802-10

Magnetic Recessed Lighting / Minimalist Ceiling Lighting / Architectural Lighting

Power
10 W
Luminous Flux
1000 Lm
CCT
3000 K;4000 K
CRI
90;97
Beam Angle
120 deg
IP Rating
IP20
Installation
Embedded

Configure Your Product

Base Model
Selected ConfigurationPlease select a base model

Models

Variants

ModelPowerFluxSizeCCTCRIBeamHousingDriverDimming
Dot Trimless10 W1000 lmDia 100*H27 mm3000 K;4000 K;6000 K90;973 deg;4 deg;7 deg;15 deg;24 deg;36 deg;50 degBlack;WhiteEaglerise;Lifud;Philips

Technical Data

Technical Specifications

Input Voltage48 V AC
Power10 W
Luminous Flux1000 Lm
Efficacy100 Lm/W
CCT3000 K;4000 K
CRI90;97
SDCM3
Beam Angle120 deg
UGR<19
IP RatingIP20
Power Factor0.6
Lifetime50000 h
MaterialAluminum
FinishWhite;Black
InstallationEmbedded
Operating Temperature-20 to 40 C

Project Options

OEM Options

Custom wattageCCTCRIBeam angleFinishDriverLogoPackaging
