Dot Trimless Series / Grille Light
Dot Trimless 48V 9W Magnetic Recessed Foldable Grating Lamp, 12-Head Linear Embedded Led Ceiling Grille Light
- 9 W
- 90;97
- 24 deg 36 deg
Dot Trimless Series
Dot Trimless 48V Magnetic Recessed Round Antiglare Spot Light, 7W Embedded Led Ceiling Light
SKU D2801-7
Comfortable Light + Anti-Glare + Uniform Illumination
- Power
- 7 W
- Luminous Flux
- 700 Lm
- CCT
- 3000 K;4000 K
- CRI
- 90;97
- Beam Angle
- 24 deg;36 deg
- IP Rating
- IP20
- Installation
- Embedded
Configure Your Product
- SKU
- Power
- Luminous Flux
- Size
Selected ConfigurationPlease select a base model
Models
Variants
| Model | Power | Flux | Size | CCT | CRI | Beam | Housing | Driver | Dimming |
|---|---|---|---|---|---|---|---|---|---|
| Dot Trimless | 7 W | 700 lm | Dia 80*H38 mm | 3000 K;4000 K;6000 K | 90;97 | 3 deg;4 deg;7 deg;15 deg;24 deg;36 deg;50 deg | Black;White | Eaglerise;Lifud;Philips |
Technical Data
Technical Specifications
| Input Voltage | 48 V AC |
|---|---|
| Power | 7 W |
| Luminous Flux | 700 Lm |
| Efficacy | 100 Lm/W |
| CCT | 3000 K;4000 K |
| CRI | 90;97 |
| SDCM | 3 |
| Beam Angle | 24 deg;36 deg |
| UGR | <19 |
| IP Rating | IP20 |
| Power Factor | 0.6 |
| Lifetime | 50000 h |
| Material | Aluminum |
| Finish | White;Black |
| Installation | Embedded |
| Operating Temperature | -20 to 40 C |
Project Options
OEM Options
Custom wattageCCTCRIBeam angleFinishDriverLogoPackaging
Continue Selection
